Technical specifications:
Capacity 5500kg
Lifting height 2005mm
Total height 5410mm
Height to limit switch 5266mm
Total width3496mm
Drive through width 2613mm
Front lifting arms 790-1700mm
Rear lifting arms 790-1700mm
Distance between columns 2880mm
Power 400V 50Hz 3Ph
Motor 3kw
Lifting time 60sek
Weight 1300kg
Capacity 5500kg
Lifting height 2005mm
Total height 5410mm
Height to limit switch 5266mm
Total width3496mm
Drive through width 2613mm
Front lifting arms 790-1700mm
Rear lifting arms 790-1700mm
Distance between columns 2880mm
Power 400V 50Hz 3Ph
Motor 3kw
Lifting time 60sek
Weight 1300kg
