Produkta informācija
Drilling performance
Drilling performance steel (S235JR)24 mm
Continuous drilling performance steel (S235JR)20 mm
Drilling table
Workspace length280 mm
Workspace width300 mm
T-groove typediagonal
T-groove size14 mm
Max. distance spindle - drilling table515 mm
Electric Data
Supply voltage230 V
Phase(s)1 Ph
Current typeAC
Mains frequency50 Hz
Machine base
Max. distance spindle - machine base590 mm
Work area length260 mm
Work area width280 mm
Motor(s)
Spindle motor drive output1,5 kW
Speed range100 – 5950 min¯¹, 4 steps, electronically adjustable
Spindle
Quill stroke85 mm
Spindle chuckMT 2
Reach 165 mm
