Product info
Rim diameter: 10"-22"
Outside clamping range: 10"-20"
Inside clamping range: 12"-22"
Max wheel width: 330 mm
Max. Wheel diametre: 1000 mm
Breaking force: 12 kN
Rotation speed: CW 8 rpm CCW 8 rpm
Speed control: Switch
Max. torque: 1020 Nm
Capability: 70 kg
Power supply: 400 VAC 3ph 50Hz
Power supply (Amperage): 5 A
Installed motor power: 0,75 kW
Dimensions LxWxH: 900 x 1600 x 1850
Net weight: 180 Kg
- Weight 231 kg
- Weight with package 231 kg
- Sales unit pcs
- GTIN / EAN 8054081193108
- Manufacturer part number EEWH569AE1
