Product info
Drilling/milling output
Max. size milling head76 mm
Max. size shaft milling cutter25 mm
Drilling performance steel (S235JR)24 mm
Continuous drilling performance steel (S235JR)25 mm
Electric Data
Supply voltage400 V
Mains frequency50 Hz
Electrical connections
Total rated value3 kW
Milling table horizontal
Table length1370 mm
Table width254 mm
T-groove size16 mm
T-groove number3
Max. load bearing capacity300 kg
Travel
X axis manual820 mm
Y axis manual410 mm
Z axis manual400 mm
X axis automatic740 mm
Y axis automatic330 mm
Z axis automatic320 mm
Vertical spindle
Reach0 – 420 mm
Spindle chuckISO 40 DIN 2080
Speed range60 – 4200 min¯¹
Number of gears2
Vertical spindle speed controlmechanically stepless
Vertical spindle quill diameter86mm
Quill stroke127 mm
Vertical spindle quill feed0.04 / 0.08 / 0.15mm/rev
Vertical spindle milling head travel Y axis470mm
Vertical spindle normal operation 2.2 kW
